Physical Design and Contents |
|
| Datasheet | OMEN 1000W Power Supply - ATX 3.1 Fully Modular 80 Plus Gold |
| Dimensions (W x D x H) | 5.9 x 6.29 x 3.38 in (150 x 160 x 86 mm) |
| Weight | 5.57 lb (2.53 kg) |
| What's in the box | PSU; Full cable set; Cable bag; 4 x screws; 9 x Cable ties; HP Installation Guide |
Power Output and Efficiency |
|
| Power output maximum | **1000 W** |
| Efficiency certifications | **80 Plus Gold**; Cybenetics Platinum |
| Standard compliance | **ATX 3.1**; EPS 12V V2.92 |
| Input voltage | 100 - 240 V AC, 50/60 Hz, 12A - 6A |
| DC Output Rails | +3.3V (20A); +5V (20A); **+12V (82A)**; +5V SB (3A) |
Cables and Connectivity |
|
| Modularity | **Fully Modular** |
| GPU Support | **12V-2x6 (PCIe 5.1)** and 12VHPWR (up to 600W support) |
| Connectors | 1 x ATX 24-pin; 2 x EPS 8-pin (4+4); 2 x PCIe 8-pin (6+2); 6 x SATA; 4 x PATA |
Cooling and Reliability |
|
| Fan specifications | 135 mm Fluid Dynamic Bearing (FDB) fan with **Zero-RPM mode** |
| Acoustics | Cybenetics A+ noise certified (<28 dBA at max load) |
| Components | 100% **Japanese capacitors** rated up to 105°C |
| Operating life | 100,000 MTBF hours @ 30°C |
Safety and Warranty |
|
| Safety Protocols | OVP; UVP; OCP; SCP; OTP; OPP |
| Warranty | **HP ten-year limited warranty** |
